Date Added: July 1, 2024
High pressure oil pipe joint sealing gasket for metric inch screw gasket, oil resistant, high pressure resistant, good sealing effect, butyl + carbon steel, high temperature resistant, reusable.
Product Description
Brand：AtlanTec
Name: High Pressure Washers
Material：NBR+Carbon Steel
Temperature: -25°C~+ 100°C
Working Pressure：400KA/CM(39.2MPA)
Suitable for: hydraulic equipment, medical equipment, packaging machinery, food machinery, automobile protection equipment, household appliances, metallurgical equipment, forging machinery, factory workshops, etc.
Product Description:
Composed of metal gasket and rubber compound, has oil as the medium, for threaded pipe joints and screw plugs sealing, the gasket is a washer in the parts between the connected parts and the nut. The metal washer ensures that the components are reliably connected and securely fastened. The thickness of the retaining ring limits the amount of compression of the elastomer seal, eliminating the phenomenon of exceeding the limiting torque at the union, and therefore ensuring a reliable sealing system. Internal pressure increases the sealing force by applying force to the sealing lip. Combination gaskets are widely used in oil-based piping systems for static sealing of end faces of welded, ferrule, expanded fittings, screw plugs and pressure systems of mechanical devices.
